The BuildEx Advantage
Life Cycle Cost
The current use of any building material is predicated on cost, functionality, durability, aesthetics, or a combination of these. The traditional first cost methodology of owners, designers and public officials around the world has contributed to a non-sustainable system. Decisions based on first cost most often ignore life-long maintenance, rehabilitation and operating cost. Life cycle costing is the only way to properly evaluate the sustainability of a project.
The initial cost of Buildex® lightweight aggregate per cubic yard is usually higher than a comparable unit of normal weight aggregate. But when analyzed from a holistic or product -use perspective, the energy savings it provides almost always offset the initial cost and typically produce significant net savings. These savings come from weight reduction that results in a reduction of overall materials being used, and in construction and performance efficiencies.
The up-front cost of components manufactured with Buildex® lightweight aggregate is more than offset by the cost savings in the following areas: labor, lower dead loads, better fire resistance resulting in reduced concrete thickness, and less reinforcing required in building frames, girders, piers, and footings. For example, when compared to lightweight and normal weight concrete on a bridge with an 8-inch thick deck, where the LWC has a $20 per CY premium, the finished deck cost is generally less than 1% higher.
Embodied Energy
The embodied energy to manufacture rotary kiln structural lightweight aggregate includes mining, manufacturing, and transporting the material to the jobsite, soil blender, or building product manufacturer. The cost of this embodied energy is often paid back in a very short period, because of the improved thermal performance, lower transportation costs, and reduction of labor costs associated with the building elements. For example, the following embodied energy payback using expanded shale, clay and slate in concrete masonry is less than one year.
It is well documented that the total embodied energy to build a building is only one to three percent of the total occupant energy used by that building over its useful life (Construction Technology Laboratories report project number 180028 conducted for Buildex® lightweight aggregate 2001). Considering that up to 99 percent of the energy used throughout the building life cycle is primarily a function of climate and occupant behavior, it becomes obvious that our biggest energy resource is efficiency.
Environmental Benefits
Sustainable construction design requires a concern for minimal maintenance and energy demands, balanced again the need for efficiency and long-term performance. There are many changes that can be accomplished in the present that will yield positive results for humanity now and in the future. We believe the utilization of Buildex® lightweight aggregate with all its positive benefits is an important element in the sustainability of the building industry.
Energy Savings
Reducing the concrete density increases its thermal resistance. For example, concrete at 90 lb./ft3 has an R value of 0.26/inch while the R value for 135 lb./ft3 concrete is approximately .10/inch. In other words, the 90 lb./ft3 concrete has a 260 percent better insulation factor than the 135 lb./ft3 concrete (Buildex® lightweight aggregate Information Sheet 3201, 1999).
